Lifedent Le Ray Floor-Mounted X-ray Uint
With the unique interface design, the operator can quickly learn how to use Le Ray X-ray machine. Also, when facing different tooth positions and patient sizes, the operator can easily configure the exposure parameter on the same page, and fine-tune the final calculated exposure time.
Perfect X-ray imaging, crafted by details
A good match for all kinds of X-ray receivers
Highly personalized, extra user-friendly
Stable X-ray output provides excellent imaging quality. The pipe head is made of light materials, which can be moved easily and positioned wherever you want.
2mA tube current and 70kV tube voltage，provide high-quality images for diagnosis.DC X-ray tube.
is simple and accurate.
The DC generator keeps the patient dose to the minimum.
Automatic detection and correction for mains voltage fluctuations. X-ray output is not affected by voltage fluctuation.
High-strength alloy and lead coated tube head minimize X-ray leakage.
The accurate tube head overheating protection program will start when the temperature exceeds 60 degrees.
Back-up timer will make SIRAY and SIRAY PLUS much safer during operation.
In case of emergency during exposure
release the exposure button to terminate exposure.
The imaging quality is better， with Lifedent digital intraoral X-ray imaging system.
Floor fixed type
Wall fixed type
Floor support
Mobile bracket
Supply voltage
Power frequency
Input power
High frequency generator
X-ray tube
Ray focus
Tube voltage
AC220V
50Hz
900VA
100K-200KHZ
Canon D-0711
0.4mm
55kV / 60kV / 65kV / 70kV
Tube current
Total filtration
Inherent filtration
Leakage emissivity
Load cycle
Time of exposure
4mA / 7mA
≥1.5mmAl (70kV)
≥1mmAl (70kV)
1m＜0.25mGy/h
1 / 60
0.02 - 3.2s
